First Normal
Form (1NF) – Eliminate Repeating Groups: A
relation R is said to be in First Normal Form (1NF) if and only if all the
attributes of the relation R are atomic
in nature. A table (relation) is in 1NF if
Second Normal Form (2NF) – Eliminate Redundant Data: A relation R is said to be in Second Normal Form (2NF) if and only if
Third Normal Form (3NF) – Eliminate Columns Not Dependant On Key: A relation R is said to be in Third Normal Form (3NF) if and only if
Boyce-Codd Normal Form (BCNF): A table is in BCNF if it is in 3NF and if every determinant is a candidate key. A 3NF relation is almost always in BCNF. However, the following conditions define some situations when a 3NF relation may not be in BCNF:
Fourth Normal Form (4NF) – Isolate Independent Multiple Relationships: A table is in 4NF if it is in BCNF and if it has no multi-valued dependencies.
Note: No table may contain two or more 1:n or n:m relationships that are not directly related.
Fifth Normal Form (5NF) – Isolate Semantically Related Multiple Relationships: A table is in 5NF, also called "Projection-Join Normal Form" (PJNF), if it is in 4NF and if every join dependency in the table is a consequence of the candidate keys of the table.
Note: There may be practical constrains on information that justify separating logically related many-to-many relationships.
Domain-Key Normal Form (DKNF): A table is in DKNF if every constraint on the table is a logical consequence of the definition of keys and domains. It is a model which is free from all modification anomalies.
Summary of the normalization steps:
- There are no duplicate rows in the table
- Each cell is single-valued (i.e., there are no repeating groups or arrays)
- Entries in a column (attribute, field) are of the same kind
Second Normal Form (2NF) – Eliminate Redundant Data: A relation R is said to be in Second Normal Form (2NF) if and only if
- It is in the First Normal Form (1NF), and
- No partial dependency exists between non-key attributes and key attributes
Third Normal Form (3NF) – Eliminate Columns Not Dependant On Key: A relation R is said to be in Third Normal Form (3NF) if and only if
- It is in Second Normal Form (2NF)
- No transitive dependency exists between non-key attributes and key attributes
Boyce-Codd Normal Form (BCNF): A table is in BCNF if it is in 3NF and if every determinant is a candidate key. A 3NF relation is almost always in BCNF. However, the following conditions define some situations when a 3NF relation may not be in BCNF:
- The candidate keys are composite
- There are more than one candidate keys in the relation
- There are some common attributes in the relation
Fourth Normal Form (4NF) – Isolate Independent Multiple Relationships: A table is in 4NF if it is in BCNF and if it has no multi-valued dependencies.
Note: No table may contain two or more 1:n or n:m relationships that are not directly related.
Fifth Normal Form (5NF) – Isolate Semantically Related Multiple Relationships: A table is in 5NF, also called "Projection-Join Normal Form" (PJNF), if it is in 4NF and if every join dependency in the table is a consequence of the candidate keys of the table.
Note: There may be practical constrains on information that justify separating logically related many-to-many relationships.
Domain-Key Normal Form (DKNF): A table is in DKNF if every constraint on the table is a logical consequence of the definition of keys and domains. It is a model which is free from all modification anomalies.
Summary of the normalization steps:
Input Relation
|
Transformation
|
Output Relation
|
All Relations
|
Eliminate variable length record. Remove multi-attribute lines in table. |
1NF
|
1NF
|
Remove dependency of non-key attributes on part of a multi-attribute key. |
2NF
|
2NF
|
Remove dependency of non-key attributes on other non-key attributes. |
3NF
|
3NF
|
Remove dependency of an attribute of a multi attribute key on an attribute of another (overlapping) multi-attribute key. |
BCNF
|
BCNF
|
Remove more than one independent multi-valued dependency from relation by splitting relation. |
4NF
|
4NF
|
Add one relation relating attributes with multi-valued dependency. |
5NF
|
